LEXA

KNX IP Router with Secure (DIN, 1-line)...

KNX GATEWAYS

Category List: GATEWAYS & INTERFACES, Sub Category: [], Series Name: LEX-SECURE, Brand: LEXA, Short Description: Lexa KNX IP Router with Secure (DIN, 1-line) 2SU MDRC , Dimension: 90x36x64mm, Material: Plastic, Body Finish: Beige, Remarks: PARAMETERS:-, Power supply, Bus voltage: 21-30V DC, via KNX bus, Bus current: <19.5mA, 24V; <15.5mA, 30V, Bus consumption: <470 mW, Connections, LAN: RJ45 socket for 10/100 Base-T, Operation and display, LAN LED: On: The network is connected normally. Flashing: The telegram traffic between the device and the network, KNX LED: On: The KNX bus connects normally. Flashing: The telegram traffic between the KNX bus and the device, Programming the LED and button: For assigning the physical address, Temperature: , Operation: -5°C~+45°C, Storage: -25°C~+55°C, Transportation: -25°C~+70°C, Ambient<, > Humidity: <93%, except dewing, Design: Standard 35mm DIN rail installation,

Available Finishes · 1

Beige
